Product Description
The Dragon Breath SS-Series pool heaters provide a simple method of heating swimming pool water indirectly from a central heating boiler. All Dragon Breath SS-Series pool heaters are manufactured entirely of stainless steel 316L to ensure corrosion resistance to the chlorinated pool and spa water and longer equipment life. If there is standing chlorine left in the exchanger, this will cause some pitting and premature deterioration.
Dragon Breath SS-Series pool heat exchangers heat swimming pool water indirectly from a central heating hot water boiler, a solar-heated glycol loop, or a geothermal loop. These heat exchangers are highly efficient since you are utilizing the higher efficiency of the boiler instead of the lower efficiency direct heated gas-fired pool heaters. The Dragon Breath SS-Series heat exchangers are flexible and can be used for many applications including maintaining temperatures of spas, hot-tubs, swimming pools, aquaculture freshwater pond heating, and also fountain water heating.
Typical Applications
- Pool and Spas Application
Specs:
- 370,000 BTU
- With the high flow rate of the pool water going through the shell and boiler water through the tubes, low-pressure drop is achievable
- Easy selection based on pool volume
- Pool Size: Up to 28,000 gal
- Tube Side Port: 1"
- Shell Side Port: 1.5"
Features:
- 100% Stainless Steel 316L to ensure corrosion resistance for chlorine pools and spas
- Rugged construction with heavy gauge material allows for long uninterrupted life of the heat exchanger
- Due to the high flow rates through the heat exchangers, it inherently is a self-cleaning equipment
- Low-pressure drops
Benefits:
- Corrosion Resistant Self Cleaning
- Compact Design
- Low-Pressure Drops
- Sturdy Construction
- Long Life
- Suitable for Chlorine Pools
Applications:
- Swimming pools, spas, and hot tubs
- Domestic hot water
- Wastewater heat recovery
- Freshwater Aquaculture Aquaponics, Pisciculture
Standard Material:
- Tube Stacks: SS316L
- Shell: SS316L
- Maximum Pressure Rating: 150 PSIG
- Maximum Temperature Tube Side: 250º F
- Maximum Temperature Shell Side: 230º F
