PRODUCT INFORMATION
SUMP PUMP BATTERY BACKUP
General Application
Easiest thing to install... Simply plug sump pump into the 443PS and attach deep cycle battery (pickup at your local automotive shop) Your done..! When power goes out, it automatically goes to battery power and when power returns, it charges the battery again... Nothing you need to do....
SUMP PUMP BATTERY BACKUP
MODEL 443ps
Battery Back Up For Sump Pumps
600 Watt Capacity
443PS Pump Sentry is an advanced sump pump emergency battery backup system designed specifically for use with high-efficiency sump pumps drawing less than 600W. It interfaces between a pump and its AC wall outlet. When AC utility power is present, the 443PS charges a battery and monitors the wall outlet to detect a power outage. At the moment utility power fails, the 443PS draws energy from a battery and converts it to enable pump operation. When utility power returns, the 443PS automatically switches the pump back to AC wall outlet power. At the same time, the 443PS resumes charging the battery to return it to full capacity in preparation for the next power failure.
It has to be a deep cycle battery because the plates on an automotive battery will sulfate and rot much faster over time.
General Application
To determine compatibility with pump: User should verify that steady-state pump current does not exceed 5A
Features
- Rugged Aluminum Housing
- Power Output Indicator
- Battery Charge State Indicator
- Battery Replace Indicator
- 12A Start Current Capacity (2 seconds)
- Low battery audible alarm
- Battery Cables Included
- Compact Size
- For Wall Mount or Surface Mount Installation
- 2 Year Factory Warranty
- Made and serviced in the USA
Advantages
- Operates Common AC Pumps
- Instant Automatic Power Transfer
- Supports Full Pump Capacity
- Does Not Occupy Sump Pit Space
- Can Be Easily Installed
- Silent and Clean Operation
It has to be a deep cycle battery because the plates on an automotive one will sulfate and rot much faster over time.
How to Calculate Operating Time During Power Outage- Please see:
More Information
Specifications:
Easiest thing to install... Simply plug sump pump into the 443PS and attach deep cycle battery (pickup at your local automotive shop) Your done..! When power goes out, it automatically goes to battery power and when power returns, it charges the battery again... Nothing you need to do....
443PS Pump Sentry is an advanced sump pump emergency battery backup systems designed specifically for use with high efficiency sump pumps drawing less than 600W. It interfaces between a pump and its AC wall outlet. When AC utility power is present, the 443PS charges a battery and monitors the wall outlet to detect a power outage. At the moment utility power fails, the 443PS draws energy from a battery and converts it to enable pump operation. When utility power returns, the 443PS automatically switches the pump back to AC wall outlet power. At the same time, the 443PS resumes charging the battery to return it to full capacity in preparation for the next power failure.
General Application
To determine compatibility with pump: User should verify that steady state pump current does not exceed 5A
Features
- Rugged Aluminum Housing
- Power Output Indicator
- Battery Charge State Indicator
- Battery Replace Indicator
- 12A Start Current Capacity (2 seconds)
- Low battery audible alarm
- Battery Cables Included
- Compact Size
- For Wall Mount or Surface Mount Installation
- 2 Year Factory Warranty
- Made and Serviced in the USA
Advantages
Operates Common AC Pumps
- Instant Automatic Power Transfer
- Supports Full Pump Capacity
- Does Not Occupy Sump Pit Space
- Can Be Easily Installed
- Silent and Clean Operation
It has to be a deep cycle battery because the plates on an automotive one will sulfate and rot much faster over time.
Pump Compatibility
To determine compatibility with pump: User should verify that steady state pump current does not exceed 5A
Size: 33 Brand: SEC AmericaMade In USA: Yes
