PRODUCT INFORMATION
Product Description
Dynamically balanced, the NBK Replaces the Dayton 6FHX8 (4C446) Blowers, mounts in any position and operates with minimal noise and vibration to maintain CFM at higher static pressures.
This is probably the most used blower in the outdoor wood furnace industry. The NBK Blower is better Quality and will last longer than the Dayton Products. We no longer Carry any Dayton Products.
Typical Applications
This Fan is used on the WoodMaster 4400 & 5500, HeatSource Model 1000 & Taylor T-750, This Fan is also used on the Heatmor 200css & 400css, Heatmore 200SSR2 &400SSR2, Johnson John (Jr models), Freedom Outdoor Eliminator and many other applications.
Performance Data
- CFM @ 0.000-In SP: 148
- 115 Volts, 50-60 Hz, 1 Phase
- Max Ambient Temp: 104 Deg F
- Full Load Amps: 0.75
- Motor RPM: 3120
- Dimensions: Wheel diameter 3 13/16'', wheel width 2 1/2'', inlet diameter 3 1/8''
Features
- Automatic Thermal Protection
- Noise and vibration are held to a minimum to maintain CFM at higher static pressures.
- Direct replacements for many OEM blowers with the same physical footprint
- All-position mounting
- Lead Length 6"
- Min./max. operating temp. range: -20 Degree to 104 Degree F
- Blower Outlet Shape: Rectangular
- Replacement for Dayton 1TDP7, 6FHX8, 4C446
More Information
Specifications:
Size: 22
Brand: NBK
| Item | OEM Blower | |
| Type | Forward Curve, Direct Drive | |
| Wheel Dia. (In.) | 3-13/16 | |
| Wheel Width (In.) | 2-1/2 | |
| CFM @ 0.000-In. SP | 148 | |
| CFM @ 0.100-In. SP | 141 | |
| CFM @ 0.200-In. SP | 135 | |
| CFM @ 0.300-In. SP | 129 | |
| CFM @ 0.400-In. SP | 121 | |
| CFM @ 0.500-In. SP | 114 | |
| Voltage | 115 | |
| Hz | 60/50 | |
| Phase | Single | |
| Full Load Amps | 0.68/0.75 | |
| RPM | 3120 | |
| Bearing Type | Sleeve | |
| Motor Type | Shaded Pole | |
| Motor Enclosure | Open Dripproof | |
| Thermal Protection | Auto | |
| Lead Length (In.) | 6 | |
| Conduit Box | Yes | |
| Ambient Temp. (Deg. F) | 104 | |
| Max. Inlet Temp. (Deg. F) | 104 | |
| Inlet Dia. (In.) | 3-1/8 | |
| Outlet Height (In.) | 2-1/16 | |
| Outlet Width (In.) | 3-1/4 | |
| Overall Height (In.) | 5-3/4 | |
| Overall Width (In.) | 7-1/2 | |
| Overall Depth (In.) | 5-5/16 | |
| Mounting | All Position | |
| Housing Finish | Black Baked Enamel | |
| Housing Material | Steel | |
| Agency Compliance | UL Component Recognized, CSA Certified |
