Exhaust Fan 18" Dia, 2504 CFM, 115 v, 22" x 22"

$365.00

Quick Shipment

SKU: UHF20a

MANUFACTURER: AH&S

  • Propeller Material: Stamped Aluminum
  • Motor Type: Shaded Pole
  • 115 Volts, 60 Hz, 1 Phase
  • Full Load Amps: 1.7, Motor RPM 1050 - 2 Speed
  • Bearing Type: Ball
PRODUCT INFORMATION
More Information
PRODUCT INFORMATION

Product Description

Exhaust Fan, Medium Duty Direct Drive, Propeller Dia 20 In, 3647 CFM @ 0.000-In SP, @ 0.125-In SP 2995, @ 0.250-In SP 2310, 12.5 Sones @ 0.125-In. SP @ 5 Ft., Max Ambient Temp 104 Deg F, 115 Volts, 60 Hz, 1 Phase, Full Load Amps: 2.8, Motor RPM 1150, HP 1/4, Bearing Type:Ball, MotorType: Shaded Pole, Height 24 In, Width 24 In, Max Depth 9 5/8 In, Vertical Mounting Position, Frame Material: Galvanized Steel, Propeller Material: Stamped Aluminum, Number of Blades 3, Speed Controllable with SC36

Typical Applications

Great for ventilating schools, offices, storage facilities, and light manufacturing and assembly areas.

Performance Data

  • Motor Type: Shaded Pole
  • 115 Volts, 60 Hz, 1 Phase
  • 2504 CFM
  • Propeller Diameter: 18''
  • Max Ambient Temp: 104 Deg F
  • Full Load Amps: 1.7
  • Motor RPM: 1050 - 2 Speed
  • HP: 1/9
  • Dimensions: Height 22'', Width 22'', Max Depth 10''

Features

  • Direct-Drive Venturi Exhaust Fans
  • Fans are UL and C-UL Listed.
  • Vertical mounting position
  • Motors: totally enclosed
  • Motor Type: Shaded Pole
  • Ball bearings
  • Aluminum blades
  • Optional speed controls sold separately
  • Stamped blades quietly exhaust high volumes of air.
More Information
Specifications:

Untitled document

Item   Exhaust Fan
Type   Medium Duty Direct Drive
Propeller Dia. (In.)   18
CFM @ 0.000-In. SP   2504
CFM @ 0.125-In. SP   2035
CFM @ 0.250-In. SP   884
Sones @ 0.125-In. SP @ 5 Ft.   9.5
Voltage   115
Hz   60
Phase   1
Motor HP   1/9
Motor Type   Shaded Pole
Motor Enclosure   Totally Enclosed Air-Over
Motor Insulation   Class B
Bearing Type   Ball
Motor RPM   1050
Max. Ambient Temp. (F)   104
Height (In.)   22
Width (In.)   22
Max. Depth (In.)   10
Flange Width (In.)   1
Mounting Position   Vertical
Frame Material   Galvanized Steel
Frame Finish   Galvanized Steel
Guard Material   Steel Wire
Wire Guard Finish   Zinc Plated
Propeller Material   Stamped Aluminum
Number of Blades   4
Agency Compliance   UL Listed, AMCA Licensed
Dimension B (In.)
Dimension C (In.)
Dimension D (In.)
For Use With   General Ventilation Applications
Size: 16
Brand: AHS
