NBK Blower Replaces Dayton 1TDT7 Blower 542/409 CFM 2-Speed 1380/1045 RPM 115V 60/50hz (4C566)

$229.99$199.99

You Save: $30.00 (14%)

Quick Shipment

SKU: FN1TDT7

MANUFACTURER: NBK

  • Voltage 115, 50/60 Hz, Single Phase.
  • Full Load Amps 2.0, RPM 1380/1045
  • Max Inlet Temp 104 Deg F
  • Overall Height 11 1/8", Overall Width 9 1/16", Overall Depth 10 7/16
  • High Quality with less failures
PRODUCT INFORMATION
More Information
PRODUCT INFORMATION

Product Description

Dynamically balanced, the NBK Blower mounts in any position and operates with minimal noise and vibration, to maintain CFM at higher static pressures. Open motor has cast-aluminum end shields for greater heat dissipation, resulting in less downtime and longer service life.

This Blower is equivalent to:

Dayton 1TDT7, Fasco 7008-6164, Dayton 4C566, Fasco A455

Performance Data

  • CFM @ 0.000-In SP 273
  • 115 Volts, 50-60 Hz, 1 Phase
  • Max Ambient Temp: 104 Deg F
  • Operating Amps: 1.4
  • Full Load Amps: 2.17/1.61
  • Motor RPM: 1380/1045
  • Dimensions: Height 11 1/8'', Width 9 1/16'', Depth 10 7/16''

Features

  • Dynamically balanced blowers provide smooth and quiet operation.
  • Noise and vibration are held to a minimum to maintain CFM at higher static pressures. Motors have cast aluminum end shields for greater heat dissipation and protection, resulting in less downtime and longer service life. UL and C-UL Recognized (E47479), except No. 2C646 is not UL or C-UL Recognized, and No. 2C647 is UL Recognized (E22286) and CSA Certified (LR12645).
  • Direct replacements for many OEM blowers with same physical footprint
  • All-position mounting
  • Min./max. operating temp. range: -20 Degree to 104 DegreeF
  • Max. inlet and ambient temp.: 104 DegreeF
  • Motor enclosure: open
  • Replaces 4C566
  • Includes discharge mounting flange
More Information
Specifications:
  • Item OEM Blower
  • Outlet Shape Rectangular
  • With/Without Flange With Flange
  • Wheel Dia. 6-1/4"
  • Wheel Width 3-13/16"
  • CFM @ 0.000-In. SP542/409
  • CFM @ 0.100-In. SP520/398
  • CFM @ 0.200-In. SP510/387
  • CFM @ 0.300-In. SP480/375
  • CFM @ 0.400-In. SP465/362
  • CFM @ 0.500-In. SP450/348
  • CFM @ 0.600-In. SP420/337
  • CFM @ 0.700-In. SP390/300
  • CFM @ 0.800-In. SP358/270
  • Voltage 115
  • Hz 50/60
  • Phase 1
  • Full Load Amps 2.17/1.61
  • RPM 1380/1045
  • Bearing Type BALL
  • Motor Type Permanent Split Capacitor
  • Motor Enclosure Open
  • Motor Insulation Class B
  • Thermal Protection Auto
  • Lead Length 13"
  • Conduit Box Yes
  • Max. Ambient Temp. 104 Degrees F
  • Max. Inlet Temp. 104 Degrees F
  • Inlet Dia. 5-5/16"
  • Outlet Height 4-1/4"
  • Outlet Width 5-1/4"
  • Overall Height 11-1/8"
  • Overall Width 9-1/16"
  • Overall Depth 10-7/16"
  • Wheel Type Forward Curve
  • Drive Type Direct
  • Mounting Position All Position
  • Housing Finish Enamel
  • Housing Material Rolled Steel
  • Housing Color Black
  • Agency Compliance UL Recognized US and Canada (E47479), CE
  • Replaces 4C566
  • Includes Discharge Mounting Flange
Size: 24
Brand: NBK
